Networking Ultra Riser Adapter Compatibility Matrix

Model	Form Factor	Controller Type	Chipset	Port #	Connector	PCI-E Slot	NVMe Ports	Compatible Motherboards
AOC-2UR6-i4XT	2U Ultra Riser	10Gbase-T	Intel® X540	4	RJ45	1x PCI-E 3.0 x16 1x PCI-E 3.0 x8 (internal)*	0	X10DRU-i+ X10DRU-X X10QRH+
Compatible Systems SYS-2028U-TR4T+ SYS-6028U-TR4T+ SYS-2048U-RTR4
AOC-2UR66-i4G	2U Ultra Riser	GbE	Intel® i350	4	RJ45	2x PCI-E 3.0 x16	0	X11DPU X10DRU-i+ X10DRU-X X10QRH+
Compatible Systems SYS-2048U-RTR4 SYS-6028UX-TR4
AOC-2UR66-i4XTF	2U Ultra Riser	10GBase-T	Intel® XL710 + X557	4	RJ45	2x PCI-E 3.0 x16	0	X11DPU X10DRU-i+
Compatible Systems SYS-2029U-TR4T SYS-2029U-E1CR4T SYS-6029U-TR4T SYS-6029U-E1CR4T
AOC-2UR668G4	2U Ultra Riser	N/A	N/A	N/A	0	2x PCI-E 4.0 x16 1x PCI-E 4.0 x8 (internal in x16)	0	H12DSU-iN X12DPU-6
Compatible Systems SYS-220U-TNR SYS-220U-MTNR SYS-620U-TNR
AOC-2UR68-b2TS	2U Ultra Riser	25GbE	Broadcom® BCM57414	2	SFP28	1x PCI-E 3.0 x8 (in x16) 1x PCI-E 3.0 x16 1x PCI-E 3.0 x8 (internal)*	0	X11DPU
Compatible Systems TBD
AOC-2UR68-i2XS	2U Ultra Riser	10G SFP+	Intel® 82599ES	2	SFP+	1x PCI-E 3.0 x8 (in x16) 1x PCI-E 3.0 x16 1x PCI-E 3.0 x8 (internal)*	0	X11DPU X10DRU-i+ X10DRU-X X10QRH+
Compatible Systems SYS-2029U-TRTP SYS-2029U-E1CRTP SYS-6029U-TRTP SYS-6029U-E1CRTP SYS-2028U-TRTP+ SYS-6028U-TRTP+ SYS-2048U-RTR4
AOC-2UR68-i2XT	2U Ultra Riser	10Gbase-T	Intel® X540	2	RJ45	1x PCI-E 3.0 x8 (in x16) 1x PCI-E 3.0 x16 1x PCI-E 3.0 x8 (internal)*	0	X11DPU X10DRU-i+ X10DRU-X X10QRH+
Compatible Systems SYS-2029U-TRT SYS-2029U-E1CRT SYS-6029U-TRT SYS-6029U-E1CRT SYS-2028U-TRT+ SYS-6028U-TRT+ SYS-2048U-RTR4
AOC-2UR68-i4G	2U Ultra Riser	GbE	Intel® i350	4	RJ45	1x PCI-E 3.0 x8 (in x16) 1x PCI-E 3.0 x16 1x PCI-E 3.0 x8 (internal)*	0	X11DPU X11DPU-Z+ H11DSU-iN X10DRU-i+ X10DRU-X
Compatible Systems SYS-2029U-TR4 SYS-2029U-E1CR4 SYS-6029U-TR4 SYS-6029U-E1CR4 SYS-2029UZ-TR4+ SYS-6029U-TR4+ AS-2023US-TR4 SYS-2028U-TR4+ SYS-6028U-TR4+
AOC-2UR68-m2TS	2U Ultra Riser	25GbE	Mellanox® ConnectX-4 Lx EN	2	SFP28	1x PCI-E 3.0 x8 (in x16) 1x PCI-E 3.0 x16 1x PCI-E 3.0 x8 (internal)*	0	X11DPU X11DPU-Z+ H11DSU-iN
Compatible Systems SYS-2029U-TR25M SYS-2029U-E1CR25M SYS-6029U-TR25M SYS-6029U-E1CR25M SYS-2029UZ-TN20R25MAS-2123US-TN24R25M
AOC-2UR68G4-i2XT	2U Ultra Riser	10Gbase-T	Intel® X710-AT2	2	RJ45	1x PCIe 4.0 x8 (in x16) 1x PCIe 4.0 x16 1x PCIe 4.0 x8 (internal in x16)	0	H12DSU-iN X12DPU-6
Compatible Systems SYS-220U-TNR SYS-220U-MTNR SYS-620U-TNR
AOC-2UR68G4-i4XTS	2U Ultra Riser	10Gbase-T 10G SFP+	Intel® X710-TM4	4	2x RJ45 2x SFP+	1x PCIe 4.0 x8 (in x16) 1x PCIe 4.0 x16 1x PCIe 4.0 x8 (internal in x16)	0	H12DSU-iN X12DPU-6
Compatible Systems SYS-220U-TNR SYS-220U-MTNR SYS-620U-TNR
AOC-2UR68G4-m2TS	2U Ultra Riser	25GbE	Mellanox® ConnectX-6 LX	2	2x SFP28	1x PCIe 4.0 x8 (in x16) 1x PCIe 4.0 x16 1x PCIe 4.0 x8 (internal in x16)	0	X12DPU-6
Compatible Systems SYS-120U-TNR SYS-610U-TNR
AOC-2UR6N4-i4XT	2U Ultra Riser	10Gbase-T	Intel® X550	4	RJ45	1x PCI-E 3.0 x16	4	X11DPU X10DRU-i+
Compatible Systems SYS-2029U-TN24R4T SYS-2028U-TN24R4T+
AOC-2UR8N4-i2XT	2U Ultra Riser	10Gbase-T	Intel® X540	2	RJ45	1x PCI-E 3.0 x8 (in x16) 1x PCI-E 3.0 x8 (internal)	4	X10DRU-i+ X10DRU-X
Compatible Systems SYS-2028U-TNRT+ SYS-2028U-E1CNRT+ SYS-6028U-TNRT+ SYS-6028U-E1CNRT+
AOC-2URN4-i4XT	2U Ultra Riser	10Gbase-T	Intel® X540	4	RJ45	1x PCI-E 3.0 x8 (internal)	4	X10DRU-i+ X10DRU-X
Compatible Systems SYS-2028U-TNR4T+ SYS-2028U-E1CNR4T+ SYS-6028U-TNR4T+ SYS-6028U-E1CNR4T+
AOC-UR-i2XT	1U Ultra Riser	10GBase-T	Intel® X540	2	RJ45	1x PCI-E 3.0 x8 (internal)	0	X11DPU H11DSU-iN X10DRU-i+ X10DRU-X
Compatible Systems SYS-1029U-TRT SYS-1029U-E1CRT SYS-6019U-TRT SYS-6019U-TN4RT AS-1123US-TN10RT SYS-1028U-TRT+ SYS-6018U-TRT+
AOC-UR-i4G	1U Ultra Riser	GbE	Intel® i350	4	RJ45	1x PCI-E 3.0 x8 (internal)	0	X11DPU H11DSU-iN X10DRU-i+ X10DRU-X
Compatible Systems SYS-1029U-TR4 SYS-1029U-E1CR4 SYS-6019U-TR4 AS-1023US-TR4 AS-1123US-TR4 SYS-1028U-TR4+ SYS-6018U-TR4+ SYS-1028U-E1CR4+
AOC-UR-i4XT	1U Ultra Riser	10GBase-T	Intel® X540	4	RJ45	1x PCI-E 3.0 x8 (internal)	0	X11DPU X10DRU-i+ X10DRU-X
Compatible Systems SYS-1029U-TR4T SYS-1029U-E1CR4T SYS-6019U-TR4T SYS-6019U-TN4R4T SYS-1028U-TR4T+ SYS-6018U-TR4T+
AOC-URG4N4	1U Ultra Riser	N/A	N/A	0	N/A	1x PCI-E 4.0 x16 (internal)	4	H12DSU-iN X12DPU-6
Compatible Systems SYS-120U-TNR SYS-610U-TNR
AOC-URG4N4-b2XT	1U Ultra Riser	10GBase-T	Broadcom® BCM57416	2	RJ45	1x PCI-E 4.0 x16 (internal)	4	H12DSU-iN X12DPU-6
Compatible Systems TBD
AOC-URG4N4-i2XT	1U Ultra Riser	10Gbase-T	Intel® X710-AT2	2	RJ45	1x PCI-E 4.0 x16 (internal)	4	H12DSU-iN X12DPU-6
Compatible Systems AS-1024US-TRT SYS-120U-TNR SYS-610U-TNR
AOC-URG4N4-i4XTS	1U Ultra Riser	10Gbase-T 10G SFP+	Intel® X710-TM4	4	2x RJ45 2x SFP+	1x PCI-E 4.0 x16 (internal)	4	H12DSU-iN X12DPU-6
Compatible Systems AS-1124US-TNRP SYS-120U-TNR SYS-610U-TNR
AOC-URG4N4-m2TS	1U Ultra Riser	25GbE	Mellanox® ConnectX-6 LX	2	2x SFP28	1x PCI-E 4.0 x16 (internal)	4	X12DPU-6
Compatible Systems SYS-120U-TNR SYS-610U-TNR
AOC-URN2-i2XS	1U Ultra Riser	10G SFP+	Intel® 82599ES	2	SFP+	1x PCI-E 3.0 x8 (internal)	2	X11DPU X10DRU-i+ X10DRU-X
Compatible Systems SYS-1029U-TRTP SYS-1029U-E1CRTP SYS-6019U-TRTP SYS-6018U-TRTP+ SYS-1028U-TNRTP+
AOC-URN2-i2XT	1U Ultra Riser	10GBase-T	Intel® X540	2	RJ45	1x PCI-E 3.0 x8 (internal)	2	X10DRU-i+ X10DRU-X
Compatible Systems SYS-1028U-TNRT+
AOC-URN2-i4GXS	1U Ultra Riser	10G SFP+ GbE	Intel® X710 + i350	2 2	SFP+ RJ45	1x PCI-E 3.0 x8 (internal)	2	X11DPU X10DRU-i+ X10DRU-X
Compatible Systems SYS-1029U-TRTP2 SYS-1029U-E1CRTP2 SYS-6019U-TRTP2 SYS-1028U-E1CRTP+
AOC-URN2-i4XT	1U Ultra Riser	10GBase-T	Intel® X540	4	RJ45	1x PCI-E 3.0 x8 (internal)	2	X10DRU-i+ X10DRU-X
Compatible Systems SYS-1028U-TNR4T+
AOC-URN4-b2TS	1U Ultra Riser	25GbE	Broadcom® BCM57414	2	SFP28	1x PCI-E 3.0 x16 (internal)	4	X11DPU
Compatible Systems TBD
AOC-URN4-b2XT	1U Ultra Riser	10GBase-T	Broadcom® BCM57416	2	RJ45	1x PCI-E 3.0 x16 (internal)	4	X11DPU
Compatible Systems TBD
AOC-URN4-i2TS	1U Ultra Riser	25GbE	Intel® XXV710	2	SFP28	1x PCI-E 3.0 x16 (internal)	4	X11DPU X11DPU-Z+
Compatible Systems TBD
AOC-URN4-m2TS	1U Ultra Riser	25GbE	Mellanox® ConnectX-4 LX EN	2	SFP28	1x PCI-E 3.0 x16 (internal)	4	X11DPU X11DPU-Z+ X10DRU-i+
Compatible Systems SYS-1029U-TR25M SYS-1029U-E1CR25M SYS-6019U-TR25M SYS-1029UZ-TN20R25M
AOC-URN6-i2XT	1U Ultra Riser	10GBase-T	Intel® X540	2	RJ45	n/a	6	X11DPU X10DRU-i+
Compatible Systems SYS-1029U-TN10RT SYS-1028U-TN10RT+
